Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)

Vitus ZX 1 EVO CRS Road Bike Ultegra (2022) - £3,499.99

The latest Vitus ZX-1 has been remastered, reimagined and reengineered. Enter, the EVO. Lighter, stiffer and faster. Stripped right back to the drawing board for a ground-up overhaul.

Yes, we’ve done the testing and know that the EVO exhibits up to 45% less drag than the previous model. But that means nothing until you unleash it outside and feel it for yourself. In the world of aero bikes, amongst all the jargon and data, it’s easy to lose sight of what really matters. That to feel fast is to be fast, and you can’t feel fast in a wind tunnel. The pleasure of speed only exists in the real world. Out there on the road. The sensation of putting power through your pedals and feeling the bike surge underneath you. And the faster you go, the easier it becomes. That’s where the ZX-1 EVO excels. That’s the bike working with you as the road snakes and the wind changes. That’s aero.

The ZX-1 EVO doesn’t neglect everything for the sake of speed, since an uncomfortable rider cannot be fast and efficient. At least, not for long. Thanks to the one-piece carbon monocoque frame there are no points of weakness, no joints, so it is specifically engineered to be stiff where required and deliver comfort elsewhere, reducing harshness from the road for a more soothing ride feel. Reassuringly, there are no compromises on performance with the build. You’re getting trusted performance from Shimano’s Ultegra groupset, deep-section aero Reynolds carbon wheels and an integrated carbon stem and handlebar to keep the front end sleek. The result? A bike with a stunningly clean aesthetic that carves through the air with outstanding efficiency.

The performance geometry slots the rider into a naturally aerodynamic position, so whether racing flat-out, sprinting for road signs or charging on the front of the chaingang, the EVO gathers momentum quickly and holds speed with ease. We’ve made this bike fast. We know it rides fast. The rest is up to you.

  • Race-Fit geometry
  • SL UD Carbon aero frame and fork with integrated seat clamp
  • Full internal cable routing
  • Shimano Ultegra R8000 groupset
  • Reynolds AR58/62 DB Carbon wheelset
  • Prime Primavera Carbon aero handlebar


EVO Carbon Platform

Aero Race Performance

Frame Material

SL UD Carbon

Wheel Size


Available Size

XS, S, M, L, XL, XXL


Dark Sage Green


Medium: 8.2kg


Shop with Preferred Partner

    The new Vitus ZX1 EVO CRS has brought the brand’s aero offering up to date in terms of technology and aerodynamics. There is no question this a race bike through and through, and for someone who is trying to create a little drag as possible.

Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)
Vitus ZX 1 EVO CRS Road Bike Ultegra (2022)



SL UD Carbon, UCI Approved, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch

REAR HUB Reynolds GW TR3

142 x 12mm, Centre Lock, HG Freehub


SL UD Carbon, UCI Approved, Tapered Steerer, 100 x 12mm, Flat Mount, Size Specific Offset

WHEELSETReynolds AR58/AR62 DB Carbon Carbon Clincher Wheelset

700c, Tubeless Ready, 24 Hole, 100 x 12mm Front, 142 x 12mm Rear, Centre Lock, HG Freehub

CHAINSETShimano Ultegra R8000

FC-R8000, 52/36T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm

FRONT TYREMichelin Power Road TLR

700c x 25c, Tubeless Ready


BB 386EVO for 24mm axle

REAR TYREMichelin Power Road TLR

700c x 25c, Tubeless Ready

FRONT DERAILLEURShimano Ultegra R8000


BRAKESShimano Ultegra R8000 Disc

BR-R8070, Hydraulic Disc, Flat Mount

REAR DERAILLEURShimano Ultegra R8000

RD-R8000-GS, 11-Speed, Long Cage, Shadow


Front:160mm, Rear:140mm

FRONT SHIFTERShimano Ultegra R8000


HANDLEBARSPrime Primavera Carbon Aero

UD Carbon, Rise: 78mm, XS:400mm S:400mm M:420mm L:420mm XL:420mm XXL:420mm

REAR SHIFTERShimano Ultegra R8000

ST-R8020, 11-Speed

STEMFSA ST-OS-185 Integrated

Bar Bore 31.8mm, - 6 degrees, XS:100mm, S:100mm, M:110mm, L:110mm, XL:120mm, XXL:120mm

CASSETTEShimano Ultegra R8000



Sealed Bearings, 1.5" 36x45 degrees (FSA No.55ACR), Vitus/FSA Headset Cover


11 Speed

GRIPSVitus Super Grip

Anti Slip

FRONT RIMReynolds AR58

Carbon, TubelessReady, Disc Brake, Rim Depth: 58mm, Inner Rim Width: 19mm, Outer Rim Width: 28mm

SADDLEVitus Race Performance

CRN-Ti Rail, Pressure Relief Channel

REAR RIMReynolds AR62

Carbon, TubelessReady, Disc Brake, Rim Depth: 62mm, Inner Rim Width: 21mm, Outer Rim Width: 30mm


+20mm/-2mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm


100 x 12mm, Centre Lock


Internal Wedge System

  • Full Monocoque Frame

    The All New ZX-1 EVO features a true monocoque frame, manufactured as a single piece. Comfort and performance go hand-in-hand, while eliminating any joins creates greater strength and result in a light weight, eye catching frame. Less aerodynamic drag, for ultimate speed when out on the open road.

  • Dual Fork Design

    We have introduced frame size specific fork geometry maintaining fit and handling characteristics across the full size curve. By adjusting the rake on the smaller sizes this ensures handling isn't compromised, whilst at the same time giving riders the same toe overlap versus the bigger frame sizes.

  • Tyre clearance

    Performance shouldn't come about at the expense of practicality, that's why the ZX-1 EVO brings 700c x 30 tyre clearance across all sizes. For added comfort and control, without compromising on speed.

Geometry & Sizing

Measurement instructions for Vitus Sommet range


Model / Size XS S M L XL XXL
(A) Seat Tube - CT 470 490 510 530 550 570
(B) Seat Tube - CC 450 470 490 510 530 550
(C) Virtual TT 520 537 551 566 581 592
(D) Front Centre 579 590 591 599.9 611 623
(E) Wheelbase 979 990 991 1000.4 1012 1024
(F) Headtube 89.5 112.3 129.6 147.8 164.5 181
(G) Fork Rake 51 51 45 45 45 45
(H) Fork Length 370 370 370 370 370 370
(I) HT Angle 70.9 71.6 72.4 72.9 73.2 73.5
(J) ST Angle 73.6 73.5 73.4 73.3 73.2 73.5
(K) Chainstay 410 410 410 410 410 410
(L) BB Drop 70 69 69 68 68 68
Crank length N/A N/A N/A N/A N/A N/A
Max Tyre Size 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c
(M) Stack  500 522 543 562 578 595
(N) Reach 372 381 387 396 406 416
Stand Over Height 752.95 774.37 794.28 815.7 831.65 850.13
Stem length N/A N/A N/A N/A N/A N/A
Handlebar Width N/A N/A N/A N/A N/A N/A
Height  160 - 165 165 - 170 170 - 177 176 - 186 186 - 193 193 - 200
Inside Leg 68 - 74 74 - 76 76 - 79 79 - 84 84 - 87 87 - 93
Bottom Bracket N/A N/A N/A N/A N/A N/A
Headset N/A N/A N/A N/A N/A N/A
Seat Post N/A N/A N/A N/A N/A N/A
