Vitus Zenium CR Road Bike 105 (2022)

Vitus Zenium CR Road Bike 105 (2022) - £1,599.99

The Vitus Zenium CR is a modern and sporty carbon road bike. Benefitting from the influence of the top-tier Vitus performance bikes and with features that make it a step up from entry level, the Zenium is the bike that will enable you to grow as a rider.

The Zenium is loaded with great features. Firstly, the carbon frame is UCI-certified so you could, with a bit of training, race it in the Tour de France. Front and rear bolt-thru axles keep the handling predictable and contribute to the responsive feel and efficiency, especially when you are out of the saddle and working hard up the climbs. Dropped seat stays complete the modern look and allow for a touch more comfort through the seatpost on those longer rides. Disc brakes not only equip you with precise control but allow the frame to afford wider tyre clearance of up to 32mm.

This Zenium CR model is finished with Shimano’s excellent 105 mechanical groupset, so you can trust that the gear shifting will be reliable. Cables are routed internally through a neat port in the downtube, protecting them from dirt and prolonging the performance of the components.

That satisfying and rewarding experience of riding a responsive carbon road bike is where the Zenium excels. It is poised to ignite the two most important qualities of a great ride - exhilaration and fun. Call it your race bike. Call it your sportive bike. Call it your commuter. Call it your all-rounder.

  • Lightweight carbon frame & fork
  • Tapered head tube
  • Internal cable routing
  • Shimano 105 R7000 11 speed drivetrain
  • Shimano 105 hydraulic disc brakes
  • Vitus wheels and Vee Road Runner 28mm tyres

Features:

Razor Platform

Performance looks and a comfortable riding position

Frame Material

UD Carbon

Wheel Size

700c

Available Size

XS, S, M, L, XL, XXL

Colour

Peacock Blue

Weight:

Medium: 9.1kg

£1,599.99

Shop with Preferred Partner
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)
Vitus Zenium CR Road Bike 105 (2022)

Specifications

FRAMEZenium Carbon

T700 UD Carbon, Flat Mount Disc Brake, Internal Cable Routing, 142 x 12mm Hub Spacing, Axle Specifcations: 163mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch

REAR HUB Vitus KT

CRR6L4, 28h, 10/11 Speed, 12 x 142mm, Centre Lock

FORKSZenium Carbon

UD Carbon, Tapered Carbon Steerer, 100mm x 12mm

WHEELSETVitus

700c, Centre Lock Disc Brake, Stainless Steel Spokes, HG Freehub, 12mm x100mm Front, 12mm x 142mm Rear

CHAINSETShimano 105 R7000

50/34T, 11 Speed, XS:170mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL:175mm

FRONT TYREKenda Kwick Roller Sport

700c x 28c

BOTTOM BRACKETPrestine PF30

PF30 with 24mm adapters

REAR TYREKenda Kwick Roller Sport

700c x 28c

FRONT DERAILLEURShimano 105 R7000

FD-R7000-L, Braze-On, 2 x 11 Speed

BRAKESShimano 105 R7000

BR-R7070, Flat Mount, Hydraulic

REAR DERAILLEURShimano 105 R7000

RD-R7000, 11 Speed

BRAKE ROTORSShimano SM-RT70

Front: 160mm, Rear: 160mm

FRONT SHIFTERShimano 105 R7000

ST-R7020-L, 2 x 11 Speed

HANDLEBARSVitus 6061 Aluminium

XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm

REAR SHIFTERShimano 105 R7000

ST-R7020-R, 11 Speed

STEMVitus 6061 Aluminium

Bar Bore 31.8mm, +/- 7 degrees, XS:90mm S:100mm M:100mm L:110mm XL:110mm XXL:120mm

CASSETTESunrace CS-RX1

11 Speed, 11-32T

HEADSETACROS Aix 322 R3

Sealed Bearings, OD46, 41.8/28.6 - 47/33, 1 1/8” – 1 ½”, Integrated

CHAINKMC X11

11 Speed

GRIPSVitus SuperGrip

Anti Slip, Shockproof

FRONT RIMVitus Shining

DB-X21, 700c, 24 Hole,

SADDLEVitus

Steel Rail

REAR RIMVitus Shining

DB-X21, 700c, 28 Hole,

SEATPOSTVitus Carbon

27.2mm x 350mm

FRONT HUBVitus KT

TX5F-12, 24h, 12 x 100mm, Centre Lock

SEATCLAMPAluminium 31.8mm

Stainless Steel Bolt

Geometry & Sizing

Measurement instructions for Vitus Zenium range

Frame Size XS S M L XL XXL
Rec. Rider Height (Imperial) 5' 3" - 5' 5" 5' 5" - 5' 7" 5' 7" - 5' 9" 5' 9" - 5' 11" 5' 11" - 6' 1" 6' 1" - 6' 4"
Rec. Rider Height (Metric) 160 - 165cm 165 - 170cm 170 - 175cm 175 - 180cm 180 - 185cm 185 - 193cm
Rec. Inside Leg (Imperial) 28" - 29" 29" - 30" 30" - 31" 31" - 32" 32" - 33" 33" - 35"
Rec. Inside Leg (Metric) 68 - 74cm 74 - 76cm 76 - 79cm 79 - 81cm 81 - 84cm 84 - 89cm
(A) Seat Tube - CT 430mm 460mm 490mm 520mm 550mm 580mm
(B) Seat Tube - CC
(C) Virtual TT 510mm 527mm 544mm 561mm 578mm 595mm
(D) Front Centre 587.5mm 596.2mm 604.3mm 611.9mm 624.3mm 63.3mm
(E) Wheelbase 992.4mm 1001mm 1009mm 1017mm 1029.4mm 1035.5mm
(F) Headtube 110mm 130mm 150mm 175mm 200mm 225mm
(G) Fork Rake 51mm 51mm 51mm 51mm 51mm 51mm
(H) Fork Length 376mm 376mm 376mm 376mm 376mm 376mm
(I) HT Angle 70° 70.5° 71° 71.5° 72° 72.5°
(J) ST Angle 74.5° 74° 73.5° 73° 73° 72.5°
(K) Chainstay 415mm 415mm 415mm 415mm 415mm 415mm
(L) BB Drop 70mm 70mm 70mm 70mm 70mm 70mm
Crank length 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Tyre size 348mm 348mm 348mm 348mm 348mm 348mm
(M) Stack  509.2mm 527.5mm 544mm 576.3mm 602mm 625.8mm
(N) Reach 368.8mm 375mm 382mm 384.8mm 393.9mm 403.7mm
Stem length 100mm 100mm 110mm 110mm 120mm 120mm
Handlebar Width 400mm 400mm 420mm 420mm 440mm 440mm
