Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)

Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022) - £3,599.99

The Vitus Vitesse EVO CR, with SRAMs latest RIVAL wireless electronic components, is a lightweight racing road bike. But this isn’t just a bike for the rising road, because what goes up must come down. Sharp on the climbs, but also agile on descents and capable of holding speed on the flat. To be a great all-round road bike, to a win a Grand Tour even, it has to perform everywhere.

The Vitesse has been on a redesign journey, and this new EVO features our latest one-piece carbon frame. Not only does it look clean (and fast!), the seamless design has no joins and there is no extra material being used to bond the frame together, keeping weight down. So you will still get the goosebumps of excitement when you feel it for the first time. Then you’ll start rolling and realise that there is so much more going on here to benefit your riding.

The geometry is optimised, giving you control through turns whilst also being responsive to bursts of acceleration or steeper ramps. Stiffness is engineered into the frame where you need it most, so precious energy won’t be wasted - something we all need on those long, hilly days. And the modern frame clearance enables space for a bigger volume tyre as well, smoothing out those real world road surfaces.

The Vitesse EVO is a masterful climber. When you dream of dancing on the pedals, floating up legendary climbs and scorching personal bests, this is the bike you do it on. And when you roll over the top and hit the descent, there’s no teetering. No indecision, just pure control. A bike that lets you relax and carve the perfect line.

  • Race-Fit geometry
  • SL UD Carbon aero frame and fork with integrated seat clamp
  • SRAM Rival eTap AXS HRD groupset
  • Prime Attaquer Disc Road wheelset
  • Michelin Power Road 700x25c tubeless ready tyres
  • Lightweight Prime finishing kit

Features:

EVO Carbon Platform

Race Performance

Frame Material

SL UD Carbon

Wheel Size

700c

Available Size

XS, S, M, L, XL, XXL

Colour

Gunmetal Grey

Weight:

Medium: 7.7kg

£3,599.99

  • ROAD CC - Vitus Vitesse EVO CR RIVAL eTAP REVIEW

    The Vitesse EVO CR eTap AXS Rival is an absolute belter of a bike! Vitus says the new frame is stiffer yet lighter, and the geometry puts you in the right position to ride fast and hard – whether you're a racer or just like to pelt around the lanes. A full wireless eTap groupset at this price is hugely impressive, too.

    Read more...
Where can I buy Vitus bikes?

You can buy Vitus bikes directly through our exclusive retailers:

Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)
Vitus Vitesse EVO CR eTap AXS Road Bike Rival (2022)

Specifications

FRAMEVitesse EVO Carbon

SL UD Carbon, UCI Approved, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch

REAR HUB Prime RD010

142 x 12mm, Centre Lock, XD-R Freehub with Anti Bite Guard

FORKSVitesse EVO Carbon

SL UD Carbon, UCI Approved, Tapered Steerer, 100 x 12mm, Flat Mount, Size Specific Offset

WHEELSETPrime Attaquer Aluminium Clincher Disc Wheelset

700c, Tubeless Ready, 100 x 12mm Front, 142 x 12mm Rear, Centre Lock, XD-R Freehub

CHAINSETSRAM Rival D1 DUB

48/35T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm

FRONT TYREMichelin Power Road TLR

700c x 25c, Tubeless Ready

BOTTOM BRACKETSRAM DUB BB386

DUB for BB386EVO

REAR TYREMichelin Power Road TLR

700c x 25c, Tubeless Ready

FRONT DERAILLEURSRAM Rival eTap AXS

2x12 Speed, Braze-On

BRAKESSRAM Rival eTap AXS D1 Disc

Hydraulic Disc, Flat Mount

REAR DERAILLEURSRAM Rival eTap AXS

12 Speed, Short Cage

BRAKE ROTORSSRAM Paceline

Front:160mm, Rear:140mm

FRONT SHIFTERSRAM Rival eTap AXS

2x12 Speed

HANDLEBARSPrime Primavera Carbon Aero

UD Carbon, Rise: 78mm, XS:380mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm

REAR SHIFTERSRAM Rival eTap AXS

12 Speed

STEMPrime Doyenne Lightweight Aluminium

Bar Bore 31.8mm, +/- 5 degrees, XS:90mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm

CASSETTESRAM XG 1290 D1

10-33T

HEADSETACROS Aix-Low R3

Sealed Bearings, OD46, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40

CHAINSRAM Rival D1

12-Speed

GRIPSVitus Super Grip

Anti Slip

FRONT RIMPrime Attaquer

Aluminium, Tubeless Ready, Disc Brake, Rim Depth: 30mm, Inner Rim Width: 19mm, Outer Rim Width: 22mm

SADDLEVitus Race Performance

CRN-Ti Rail, Pressure Relief Channel

REAR RIMPrime Attaquer

Aluminium, Tubeless Ready, Disc Brake, Rim Depth: 30mm, Inner Rim Width: 19mm, Outer Rim Width: 22mm

SEATPOSTPrime Primavera Carbon

27.2mm, 10mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm

FRONT HUBPrime RD010

100 x 12mm, Centre Lock

SEATCLAMPVitesse EVO Integrated

Internal Wedge System

  • ONE PIECE MONOCOQUE FRAME

    A true one piece monocoque frame manufactured as a single piece of super light UD carbon. No joins, so greater strength and lighter weight.

  • DUAL FORK DESIGN

    Frame size specific fork geometry maintaining fit and handling characteristics across the full size curve.

  • IMPROVED TYRE CLEARANCE

    The new Vitesse EVO frame now has 30c tyre clearance across all frame sizes and even up to 32c depending on the rim/tyre combination.

Geometry & Sizing

Measurement instructions for Vitus Sommet range



Model / Size XS S M L XL XXL
(A) Seat Tube - CT 470 490 510 530 550 570
(B) Seat Tube - CC 450 470 490 510 530 550
(C) Virtual TT 523.9 537.1 550.9 565.6 577.7 587.7
(D) Front Centre 583 592 591 599.9 608 618.2
(E) Wheelbase 983 992 991 1000.4 1008.5 1018.8
(F) Headtube 104.5 127.3 145 162.7 179.5 196.1
(G) Fork Rake 51 51 45 45 45 45
(H) Fork Length 370 370 370 370 370 370
(I) HT Angle 70.9 71.6 72.4 72.9 73.2 73.5
(J) ST Angle 73.6 73.5 73.4 73.3 73.2 73.5
(K) Chainstay 410 410 410 410 410 410
(L) BB Drop 70 69 69 68 68 68
Crank length 165 170 172.5 172.5 175 175
Max Tyre Size 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c
(M) Stack  502.9 524 547 565 582 599
(N) Reach 375.9 381 387 396 402 410
Stand Over Height 754.39 775.37 796.27 815.7 833.64 852.12
Stem length 90 100 110 110 120 120
Handlebar Width 380 400 420 420 440 440
Height  160 - 165 165 - 170 170 - 177 176 - 186 186 - 193 193 - 200
Inside Leg 68 - 74 74 - 76 76 - 79 79 - 84 84 - 87 87 - 93
Bottom Bracket BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
Headset Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Seat Post 27.2 x 300mm 27.2 x 300mm 27.2 x 350mm 27.2 x 350mm 27.2 x 400mm 27.2 x 400mm

Help

  • FAQs
  • Tech Docs
  • What are the Torque settings on the Vitesse EVO?
  • You can find the tech documents for our Vitus Vitesse EVO here: Vitesse EVO Tech Documents
  • What gear hanger do I need for my Vitesse EVO?
  • You require Vitus Hanger #22 you can buy this from one of our retail partners below;
    Wiggle: Vitus Hanger 22
    Chain Reaction Cycles: Vitus Hanger 22
  • Where can I buy Vitus Bikes?
  • You can buy Vitus bikes directly through our exclusive retailers Wiggle and Chain Reaction Cycles
  • Do your bikes come with Warranty?
  • We offer a 5-year warranty on all our frames. On top of that we also offer an extended 2-year warranty on all components excluding wear and tear items such as bearings, brake pads, chains & cassettes etc. Our Warranty policy applies to the original owner and processed by our exclusive retail partners.To see their warranty process check: CRC & Wiggle
