ZX1 EVO CR eTap AXS Road Bike Rival

ZX1 EVO CR eTap AXS Road Bike Rival - £3,599.99

The All New ZX-1 EVO

An evolution. For it's 20th birthday the ZX-1 has been given the 'EVO' treatment. A fresh aero design, optimised by aerodynamic specialists based at the famous Silverstone race track has resulted in a frameset offering 18% less drag than the previous ZX-1. All new and much refined Race-Fit geometry including a longer top tube, lower front end and shorter chain stays gives the perfect balance of fit and control.

Fitted with SRAM's brand new Rival eTap AXS HRD with wireless electronic shifting. This 12 speed groupset offers modern gearing ratio's, advanced chain management and easy personalisation via the app. Top technology in an efficient package, with amazing value.

The CR eTap AXS is paired with Prime Attaquer tubeless ready disc brake wheels, fitted with Schwalbe's Pro ONE Performance TLE tyres. The cockpit features an integrated cable design, utiliting the FSA ACR headset system, FSA's SMR stem and Prime Primavera handlebar.

  • Race-Fit geometry
  • SL UD Carbon aero frame and fork with integrated seat clamp
  • Full internal cable routing
  • SRAM RIVAL eTap AXS HRD groupset
  • Prime Attaquer Disc Road wheelset
  • FSA SRM stem and Prime Primavera carbon handlebar

Features:

EVO Carbon Platform

Race Performance

Frame Material

SL UD Carbon

Wheel Size

700c

Available Size

XS, S, M, L, XL, XXL

Colour

Midnight Blue

Weight:

Medium: 8.1kg

£3,599.99

Where can I buy Vitus bikes?

You can buy Vitus bikes directly through our exclusive retailers:

ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival
ZX1 EVO CR eTap AXS Road Bike Rival

Specifications

FRAMEZX-1 EVO Carbon

SL UD Carbon, UCI Approved, Internal Cable Routing, 12mm x 142mm axle, Flat Mount

REAR HUB N/A

N/A

FORKSZX-1 EVO Carbon

SL UD Carbon, UCI Approved, Tapered Steerer, 100 x 12mm, Flat Mount, Size Specific
SPOKESN/A

N/A

CHAINSETSRAM RIVAL D1 DUB

48/35T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm

FRONT TYRESchwalbe ONE Performance

700c x 25, Tubeless Ready TLE, Race Guard

BOTTOM BRACKETSRAM DUB 386

DUB For BB386EVO

REAR TYRESchwalbe ONE Performance

700c x 25, Tubeless Ready TLE, Race Guard

FRONT DERAILLEURSRAM RIVAL eTap AXS

N/A

BRAKESSRAM RIVAL eTap AXS D1 Disc

Hydraulic Disc, Flat Mount

REAR DERAILLEURSRAM RIVAL eTap AXS

12 Speed, Short Cage,

BRAKE ROTORSSRAM Paceline

Front:160mm, Rear:140mm

FRONT SHIFTERSRAM RIVAL eTap AXS

N/A
HANDLEBARSPrime Primavera Carbon Aero

US Carbon, XS:400mm S:400mm M:420mm L:420mm XL:420mm XXL:420mm
REAR SHIFTERSRAM RIVAL eTap AXS

12 Speed
STEMFSA SMR ACR

Bar Bore 31.8mm, XS:100mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm

CASSETTESRAM Red 1290

10-33T
HEADSETFSA/Vitus ACR

Sealed Bearings, 1.5" 36x45 degrees (FSA No.55ACR), Vitus/FSA Headset Cover
CHAINSRAM RIVAL D1

12 Speed
GRIPSVITUS SuperGrip

Anti Slip
FRONT RIMN/A

N/A
SADDLEVITUS Race Performance

CRN-Ti Rail, Pressure Relief Channel
REAR RIMN/A

N/A
SEATPOSTZX-1 EVO Aero

+20mm/-2mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm
FRONT HUBN/A

N/A
SEATCLAMPZX-1 EVO Integrated

Internal Wedge System

  • Full Monocoque Frame

    The All New ZX-1 EVO features a true monocoque frame, manufactured as a single piece. Comfort and performance go hand-in-hand, while eliminating any joins creates greater strength and result in a light weight, eye catching frame. Less aerodynamic drag, for ultimate speed when out on the open road.

  • Race Fit Geometry

    Race-Fit geometry is reserved for Vitus' performance led race bikes. The aim is to put the rider in the most advantageous position possible, maximising power output and aerodynamic positioning, whilst maintaining comfort.

  • Dual Fork Design

    We have introduced frame size specific fork geometry maintaining fit and handling characteristics across the full size curve. By adjusting the rake on the smaller sizes this ensures handling isn't compromised, whilst at the same time giving riders the same toe overlap versus the bigger frame sizes.

  • Tyre clearance

    Performance shouldn't come about at the expense of practicality, that's why the ZX-1 EVO brings 700c x 30 tyre clearance across all sizes. For added comfort and control, without compromising on speed.

Geometry & Sizing

Measurement instructions for Vitus Sommet range



Model / Size XS S M L XL XXL
(A) Seat Tube - CT 470 490 510 530 550 570
(B) Seat Tube - CC 450 470 490 510 530 550
(C) Virtual TT 520 537 551 566 581 592
(D) Front Centre 579 590 591 599.9 611 623
(E) Wheelbase 979 990 991 1000.4 1012 1024
(F) Headtube 89.5 112.3 129.6 147.8 164.5 181
(G) Fork Rake 51 51 45 45 45 45
(H) Fork Length 370 370 370 370 370 370
(I) HT Angle 70.9 71.6 72.4 72.9 73.2 73.5
(J) ST Angle 73.6 73.5 73.4 73.3 73.2 73.5
(K) Chainstay 410 410 410 410 410 410
(L) BB Drop 70 69 69 68 68 68
Crank length N/A N/A N/A N/A N/A N/A
Max Tyre Size 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c 700 x 30c
(M) Stack  500 522 543 562 578 595
(N) Reach 372 381 387 396 406 416
Stand Over Height 752.95 774.37 794.28 815.7 831.65 850.13
Stem length N/A N/A N/A N/A N/A N/A
Handlebar Width N/A N/A N/A N/A N/A N/A
Height  160 - 165 165 - 170 170 - 177 176 - 186 186 - 193 193 - 200
Inside Leg 68 - 74 74 - 76 76 - 79 79 - 84 84 - 87 87 - 93
Bottom Bracket N/A N/A N/A N/A N/A N/A
Headset N/A N/A N/A N/A N/A N/A
Seat Post N/A N/A N/A N/A N/A N/A
