Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)

Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022) - £3,799.99

The Vitus Energie EVO CRS eTap AXS Cyclocross bike has the clean lines and sleek aesthetic of a modern carbon race bike. But its best side is not the one leaning pristine against an immaculate garage wall or sparkling for Instagram. It’s the one ready to race laps of a grassy park in the rain, slide into muddy corners, power through sand and compete in the worst winter weather.

This bike is for the passionate. This is for those who come alive on cold Sunday mornings, who delight in the rush of exciting racing. This is for those looking for the difference without compromising the basic joy of riding. Importantly, this is UCI-approved and podium-ready. A game-changer. Whether racing for the podium or just for fun, the frame is loaded with thoughtfully engineered features that are uniquely designed and refined for the demands of cyclocross. A flatter top tube sits comfortably into the shoulder and single-entry cable routing reduces penetration of dirt so that performance is not reduced by wet conditions or a jet wash. A revised carbon lay-up improves the stiffness for power out of the turns, where it really matters mid-race, while also reducing weight for when you need to carry or charge into a climb.

The top tube is slightly longer and the stem a touch shorter than before, keeping weight distribution slightly back from the front end, so the handling feels snappy and responsive - this is immediate control, whatever the conditions. Frame clearance around the Prime carbon BlackEdition 38 wheels is vast, so your speed won’t be slowed, nor the bike weighed down by mud. It also makes the bike easy to clean for your pit crew, and when the racing is done you can spray it down quickly and put it straight into the car.

A Vitus is always best being ridden, not hanging on a wall, waiting or posing. So when you’re not lining up for cyclocross, thanks to an innovative removable seat stay bridge, you can add mudguards and carry on with your winter training and year-round commuting. However hard the ride, with the Energie the fun is always turned right up. Why wouldn’t you want to keep riding this bike?

  • Race-Fit geometry
  • SL UD Carbon frame and fork
  • Huge mud clearance
  • SRAM FORCE 1x11 groupset
  • Lightweight Prime Carbon wheels
  • Race ready 33c tubeless tyres

Features:

EVO Carbon Platform

Pro level race ready performance

Frame Material

SL UD Carbon

Wheel Size

700c

Available Size

XS, S, M, L, XL

Colour

Black Quartz / Purple

Weight:

Medium: 7.7kg

£3,799.99

Where can I buy Vitus bikes?

You can buy Vitus bikes directly through our exclusive retailers:

Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)
Vitus Energie EVO CRS Cyclocross Bike eTap AXS (Force - 2022)

Specifications

FRAMEEnergie EVO Carbon

SL UD Carbon, UCI Approved, Internal Cable Routing, Removeable Seat-Stay Bridge, Removeable Front Deraileur Mount, Integrated Seat Clamp, Integrated Mudguard Mounts, 12mm x 142mm axle

REAR HUB Prime BlackEdition

24 Hole, 12 x 142mm Thru Axle, Centrelock

FORKSEnergie EVO Carbon

SL UD Carbon, Tpered Steerer, 100 x 12mm, Integrated Mudguard Mounts.

SPOKESN/A

N/A

CHAINSETSRAM FORCE 1 Carbon

D1 DUB, X-SYNC 40T, XS:170mm S:170mm M:172.5mm L:172.5mm XL:175mm

FRONT TYREMaxxis All Terrane

700c x 33mm, Tubeless Ready

BOTTOM BRACKETSRAM DUB

BB 386EVO

REAR TYREMaxxis All Terrane

700c x 33mm, Tubeless Ready

FRONT DERAILLEURN/A

N/A

BRAKESSRAM FORCE eTap AXS D1 HRD

Hydraulic Disc

REAR DERAILLEURSRAM FORCE eTap AXS D1

Medium Cage

BRAKE ROTORSSRAM Paceline

Front:160mm, Rear:140mm

FRONT SHIFTERN/A

N/A

HANDLEBARSPrime Primavera Aero Carbon

UD Carbon, 76.5mm Reach, 122mm Drop, XS:400mm S:400mm M:420mm L:420mm XL:440mm

REAR SHIFTERSRAM FORCE eTap AXS D1 HRD

12 Speed

STEMPrime Doyenne Lightweight

6061 Aluminium, bar bore 31.8mm, +/- 5 degrees, XS:80mm S:80mm M:90mm L:90mm XL:100mm

CASSETTESRAM XG-1270

10-36T

HEADSETACROS Aix 322 R3

Sealed Bearings, OD48, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 4

CHAINSRAM FORCE D1

PowerLock D1 Connector

GRIPSVITUS SuperGrip

Anti Slip

FRONT RIMPrime BlackEdition 38

700c, 24 Hole

SADDLEVITUS Race Performance

CRN-Ti Rail, Pressure Relief Channel

REAR RIMPrime BlackEdition 38

700c, 24 Hole

SEATPOSTPrime Primavera Carbon

27.2mm x 350mm, 10mm Offset

FRONT HUBPrime BlackEdition

24 Hole, 12 x 100mm Thru Axle, Centrelock

SEATCLAMPEnergie evo Integrated

Internal Wedge System

  • ONE-PIECE MONOCOQUE FRAME

    Expertly crafted with no joins, the uniquely layered continuous UD carbon frame is strong and light. And those modern, clean lines look awesome too!

  • PERFORMANCE DESIGN

    The geometry of top-tier Vitus frames has been carefully calculated to ensure that comfort, aerodynamics and power are balanced, so the ride feel is enhanced for the best performance, and enjoyment, in all conditions.

  • CLASS-LEADING MUD CLEARANCE

    Mud is slow. To combat that we’ve made the clearance between tyre and frame as wide as possible (within UCI-regulations, of course) so the bike won’t get weighed down and your drivetrain won’t clog in those wet and sticky races.

  • MUDGUARD MOUNTS

    The addition of an innovative removable mudguard mount between the seatstays gives you the option to keep using this bike beyond cyclocross racing, be that commuting, winter training or exploring remote lanes.

Geometry & Sizing

Measurement instructions for Vitus Energie EVO range



Frame Size XS S M L XL
Rec. Rider Height (Imperial) 5' 1" - 5' 5" 5' 5" - 5' 9" 5' 9" - 5' 11" 5' 11" - 6' 3" 6' 3" - 6' 7"
Rec. Rider Height (Metric) 155 - 165cm 165 - 176cm 175 - 182cm 182 - 190cm 190 - 200cm
Rec. Inside Leg (Imperial) 27" - 29" 29" - 31" 31" - 33" 33" - 35" 35" - 37"
Rec. Inside Leg (Metric) 68 - 76cm 75 - 79cm 80 - 84cm 83 - 88cm 87 - 94cm
(A) Seat Tube - CT 470 490 510 530 550
(B) Seat Tube - CC 454 474 494 514 534
(C) Virtual TT 517.8 539.3 560.1 581.9 601.8
(D) Front Centre 591 603.03 613.97 626.03 637.41
(E) Wheelbase 1007 1019 1030 1042 1053
(F) Headtube 101.2 120 142 165.93 183.23
(G) Fork Rake 45 45 45 45 45
(H) Fork Length 400 400 400 400 400
(I) HT Angle 70.3 70.8 71.5 72.1 72.5
(J) ST Angle 74.8 74.2 73.8 73.4 73
(K) Chainstay 425 425 425 425 425
(L) BB Drop 66 66 66 66 66
Crank Length 165 170 172.5 172.5 175
Max Tyre Size 700 x 45c 700 x 45c 700 x 45c 700 x 45c 700 x 45c
(M) Stack  523 542 565 590 611
(N) Reach 376 386 396 406 415
Stand Over Height 786.69 805.15 825.74 847.28 866.8
Stem length 80 90 90 100 110
Handlebar Width 400 400 420 420 440
Bottom Bracket BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
BB386 EVO
46mm ID x 86mm W
Headset Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Tapered 1 1/8" > 1 1/2"
Upper: IS41.8/28.6
Lower: IS52/40
Seat Post 350mm x 27.2mm 350mm x 27.2mm 350mm x 27.2mm 350mm x 27.2mm 350mm x 27.2mm

Help

  • FAQs
  • What are the Torque settings on the Energie EVO?
  • You can find the tech documents for our Vitus Energie EVO here: Energie EVO Tech Documents
  • What gear hanger do I need for my Energie EVO?
  • You require Vitus Hanger #22 you can buy this from one of our retail partners below;
    Wiggle: Vitus Hanger 22
    Chain Reaction Cycles: Vitus Hanger 22
  • Where can I buy Vitus Bikes?
  • You can buy Vitus bikes directly through our exclusive retailers Wiggle and Chain Reaction Cycles
  • Do your bikes come with Warranty?
  • We offer a 5-year warranty on all our frames. On top of that we also offer an extended 2-year warranty on all components excluding wear and tear items such as bearings, brake pads, chains & cassettes etc. Our Warranty policy applies to the original owner and processed by our exclusive retail partners.To see their warranty process check: CRC & Wiggle
