Vitus Venon EVO-RS Ultegra Di2 All-Road Bike

Vitus Venon EVO-RS Ultegra Di2 All-Road Bike - £4,099.99

The Vitus Venon EVO-RS Ultegra Di2 is an all-road bike to be reckoned with. Built for speed, efficiency, and versatility, the Venon borrows engineering proven in our high-performance family of road bikes and applies it in a new platform capable on any road surface. This is road, unlimited.

A chameleon at home on gravel or tarmac, the Venon is an all-road platform made in two flavors: the EVO-RS and EVO-GR. This specific bike, the Venon EVO-RS, is specced with road-specific components hung from a frame that smartly balances comfort and speed. Its sibling, the Venon EVO-GR, comes with components more typical of a gravel bike. The frame is the same, but we give you the choice to pick your poison — are you more the type hungry for washboard and dust, or do you prefer big days pounding pavement? Or, with a second set of wheels you can have the best of both worlds. The choice is yours. As a member of our EVO family of bikes, the Venon EVO-RS is a high-performance carbon all-road bike that places a premium on speed and efficiency. Here, aerodynamics matter — at the front of the bike you'll find tube shapes and integrated cable routing borrowed from our ZX-1 EVO aero road bike. At the rear of the bike, you'll find inspiration from our Vitesse EVO all-rounder, with dropped seatstays and a forgiving carbon layup for additional give when the road surface is less than ideal.

This Vitus Venon EVO-RS Ultegra Di2 is built up with Shimano's 2x Ultegra Di2 12-speed electronic drivetrain. It uses an internally routed cockpit, custom headset and integrated fork for maximum efficiency and comes stock with Micheline Power Cup 700x28c tyres that roll fast and are a little wider for comfort and grip. The Venon EVO frame can accommodate up to 45mm tyres, but we've paid special attention to its rear end to ensure the bike's snappy race bike-like feel wasn't sacrificed in the name of clearance. In this particular build, the rear tyre clearance is limited to maximum 40mm due to the position of the front derailleur.

In recent years we’ve seen the lines between gravel bikes and road bikes begin to blur. Riders are demanding more — more speed, more clearance, more versatility, and less fluff. The Venon EVO-RS is our answer to those demands.

  • Versatile frame platform that can be set up for performance gravel or endurance road
  • Aerodynamic profile with a snappy race bike-like feel
  • Electronic Shimano Ultegra Di2 2x12 Speed groupset
  • 700c Prime Attaquer V2 Aluminium Disc Wheelset
  • Quality Michelin Power Cup Classic 700 x 28c tyres
  • Full mudguard mounts with removable seat stay bridge

Features:

EVO Carbon Platform

Race Performance

Frame Material

SL UD Carbon

Wheel Size

700c

Available Size

XS, S, M, L, XL, XXL

Colour

Midnight Blue

Weight:

Medium: 7.7kg

£4,099.99

Shop with Preferred Partner
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike
Vitus Venon EVO-RS Ultegra Di2 All-Road Bike

Specifications

FRAMEVenon EVO Carbon

SL UD Carbon, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch

REAR HUB Prime SR1

142 x 12mm, Centre Lock, 36T Ratchet System, HG Freehub

FORKSVenon EVO Carbon

SL UD Carbon, Tapered Steerer, 100 x 12mm, Flat Mount, Axle Specifcations: 123mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch

WHEELSETPrime Attaquer V2 Aluminium Clincher Disc Wheelset

700c, Tubeless Ready, 100 x 12mm Front, 142 x 12mm Rear, Centre Lock, HG Freehub

CHAINSETShimano Ultegra R8100

FC-R8100, 50/34T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm

FRONT TYREMichelin Power Cup Classic TS TLR

700c x 28c, Tubeless Ready

BOTTOM BRACKETTRiPEAK 386-24

BB386EVO for Shimano 24mm Spindle

REAR TYREMichelin Power Cup Classic TS TLR

700c x 28c, Tubeless Ready

FRONT DERAILLEURShimano Ultegra R8150

FD-R8150, 2 x 12 Speed

BRAKESShimano Ultegra R8170 Disc

BR-R8170, Hydraulic Disc, Flat Mount

REAR DERAILLEURShimano Ultegra R8150

RD-R8150, 12 Speed, Shadow

BRAKE ROTORSPrime Centre Lock

Front:160mm, Rear:140mm

FRONT SHIFTERShimano Ultegra R8170

ST-R8170, 2 x 12 Speed, Wireless

HANDLEBARSPrime Primavera Carbon Aero

UD Carbon, Reach: 78mm, XS:380mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm

REAR SHIFTERShimano Ultegra R8170

ST-R8170, Wireless, 12 Speed

STEMFSA NS SMR Aluminium

Bar Bore 31.8mm, - 6 degrees, XS:90mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm

CASSETTEShimano Ultegra R8100

11-34T, 12-Speed

HEADSETZX-1/Venon Specific FSA No.84

Sealed bearing IS52/40 top/bottom, 36deg/45deg

CHAINShimano M8100

CN-M8100, 12 Speed

GRIPSVitus Super Grip

Anti Slip

FRONT RIMPrime Attaquer V2

Aluminium, Tubeless Ready, Disc Brake, Rim Depth: 30mm, Inner Rim Width: 19mm, Outer Rim Width: 22mm

SADDLEVitus Race Performance

Ti Rail

REAR RIMPrime Attaquer V2

Aluminium, Tubeless Ready, Disc Brake, Rim Depth: 30mm, Inner Rim Width: 19mm, Outer Rim Width: 22mm

SEATPOSTPrime Primavera Carbon

27.2mm, 10mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm

FRONT HUBPrime SR1

100 x 12mm, Centre Lock

SEATCLAMPVenon EVO Integrated

Internal Wedge System

  • BLUR THE LINE BETWEEN GRAVEL AND ROAD

    One bike, two personalities - this is road, unlimited. The new Vitus Venon EVO is an all-road platform built to blur the line between gravel and road. It borrows engineering and technology proven in our high-performance road bikes and applies it to a frame with tire clearance up to 45mm and a touch of additional compliance.

  • EVO

    As a member of our EVO family of bikes, the Venon is a high-performance carbon all-road bike that places a premium on speed and efficiency. Here, aerodynamics matter — at the front of the bike you’ll find tube shapes and integrated cable routing inspired by our ZX-1 EVO aero road bike. At the rear of the bike, you’ll find inspiration from our Vitesse EVO all-rounder, with dropped seatstays and a forgiving carbon layup for additional give when the road surface is less than ideal.

  • VERSATILITY

    Like any good all-road bike, it’s got space for chunky tires — up to 45mm — and solid mud clearance. But we’ve also taken inspiration from its siblings in the EVO lineup, the ZX-1 and Vitesse road bikes. The front end of the Venon is based on the ZX-1, with aerodynamic tube shapes and integrated cable routing, because even in gravel aerodynamics matter. At the rear of the bike you’ll find inspiration from our Vitesse all-rounder, with dropped seatstays and a forgiving carbon layup for additional give when the road surface is less than ideal.

Geometry & Sizing

Measurement instructions for Vitus Venon EVO range

Frame Size XS S M L XL XXL
Rec Rider Height (Imperial) 5' 3" - 5' 7 5' 6" - 5' 9" 5' 8" - 5' 11" 5' 10" - 6' 1" 6' 0" - 6' 3" 6' 2" - 6' 6"
Rec Rider Height (Metric) 160 - 170cm 168 - 175cm 173 - 180cm 178 - 186cm 183 - 191cm 188 - 198cm
Rec Inside Leg (Imperial) 26" - 29" 28" - 31" 30" - 33" 31" - 34" 33" - 36" 35" - 37"
Rec Inside Leg (Metric) 66 - 73cm 71 - 78cm 76 - 84cm 78 - 86cm 84 - 91cm 89 - 94cm
(A) Seat Tube Length - CT 460mm 480mm 500mm 520mm 540mm 560mm
(B) Seat Tube Length - CC - - - - - -
(C) Effective Top Tube Length 515mm 531mm 551mm 571mm 589mm 605mm
(D) Front Centre 592mm 597mm 609mm 620mm 629mm 643mm
(E) Wheelbase 1002mm 1007mm 1020mm 1030mm 1039mm 1053mm
(F) Headtube Length (with top cap) 102mm 120mm 143mm 168mm 187mm 206mm
(G) Fork Rake 50mm 50mm 50mm 50mm 50mm 50mm
(H) Fork Length 390mm 390mm 390mm 390mm 390mm 390mm
(I) Headtube Angle 70.7° 71.1° 71.5° 72.1° 72.5° 72.7°
(J) Seat Tube Angle 74.6° 74.2° 73.8° 73.4° 73° 73°
(K) Chainstay Length 420mm 420mm 420mm 420mm 420mm 420mm
(L) Bottom Bracket Drop 71mm 70mm 70mm 70mm 70mm 70mm
(M) Stack 518mm 539mm 560mm 587mm 607mm 625mm
(N) Reach 373mm 379mm 387mm 396mm 403mm 414mm
Crank Length 165mm 170mm 172.5mm 172.5mm 175mm 175mm
Max. Tyre Size 700 x 45c 700 x 45c 700 x 45c 700 x 45c 700 x 45c 700 x 45c
