The newest member of our award-winning eMTB range, the Vitus E-Mythique LT is a riot on the descent and a magic carpet on the climb.
Powered by our own custom tuned Bafang M510 motor system developed in partnership with Bafang, it blends the ethos of our award-winning Mythique trail bike with the downhill performance of the E-Sommet . The result is an eMTB that inspires confidence in big terrain, both up and down the mountain.
Packing 170mm of travel in the front and 160mm in the rear, it’s a long travel variation of the Mythique that incorporates learnings from our current E-Sommet range into an eMTB that is ready to ride anything. Whether it’s a steep and technical climb or after-work laps on the downhill track, the E-Mythique LT has been tested and developed to deliver.
The VRX version of the E-Mythique is built around a 170mm RockShox Yari RC fork and Super Deluxe Select R rear shock with 160mm of travel. The drivetrain is a mixed SRAM GX/NX Eagle 12-speed setup and braking is handled by the SRAM DB8 4-piston hydraulic disk brakes. Rounding out the build are tubeless WTB rims and a Nukeproof Neutron cockpit.
The new Bafang M510 motor system
To build an eMTB that performs exceptionally well, we partnered with a new drive unit manufacturer for Vitus, choosing Bafang and their M510 drive unit.
With a maximum torque of 95Nm and competitive system weight, the M510 is the perfect drive unit to power the E-Mythique LT. We developed a close partnership with Bafang and tuned the system to perform exactly to our needs, effectively cherry-picking the best features and incorporating them into our drive unit.
The M510 system is powered by an integrated 630Wh battery and a display with five custom power modes — Eco, Eco-plus, Trail, Boost, and Race — giving the rider maximum options for adjusting range and on-trail performance.
Combining this drive unit with our experience in suspension and geometry design, we have created an eMTB to be proud of. It's made to be ridden everywhere; from steep, rough trails to big days with big climbs .
The E-Mythique LT is designed to get the most out of eMTB’ing, whatever you might want that to be.
The E-Mythique LT VRX component details
- RockShox Yari RC & Super Deluxe Select R suspension
- Smooth Bafang M510 motor produces 250W max power and 95Nm torque
- Long range 630Wh internal battery
- Wide range SRAM GX/NX Eagle 1x12 speed drivetrain
- Powerful SRAM DB8 4 piston hydraulic disc brakes
- Tubeless ready WTB rims with grippy Vee Tyres
E-Mythique Electric Enduro PlatformInternal battery frame design with new Bafang M510 drive unit, optimised suspension kinematics and modern geometry. |
Frame Material6061-T6 Aluminium |
Suspension Travel (MTB Only)170mm Front, 160mm Rear |
Wheel SizeMullet - 29" Front / 27.5" Rear |
Available SizeS, M, L, XL |
ColourCool Grey |
Weight:Medium: 24.4kg (tubeless) |
£4,399.99
Specifications
 FRAMEE-Mythique 6061-T6 Double Butted Alloy Internal cable routing, post mount disc brake mounts, Boost hub spacing - 148mm x 12mm thru axle, Bafang M510 compatible. Axle Specifications: 181mm Length, 14.5mm Thread Length, M12xP1.0 Thread Pitch |
 REAR RIMWTB ST Light i30 TCS 2.0 27.5", 32H, Presta Valve, Tubeless Ready Rim Tape Installed |
 FORKSRockShox Yari RC 29" 170mm travel, Motion Control Damper, 110mm x 15mm axle, 42mm Offset |
 FRONT HUBVitus KT DHF112
32H, 6 Bolt Disc Fitment, 110mm x 15mm |
 SHOCKRockShox Super Deluxe Select R DebonAir, 205mm x 65mm, trunnion |
 REAR HUB Vitus KT H5ER-SH 32H, 6 Bolt Disc Fitment, HG Freehub, 148mm x 12mm |
 CHAINSETBafang 34T Narrow Wide Chainring, 165mm Crank Length, 53mm Chain Line |
 WHEELSETWTB ST Light i30 rims on Vitus KT hubs 29" Front, 27.5" Rear Wheelset, 32H, 6 Bolt, Boost 110mm x 15mm Front & 148mm x 12mm Rear Hub Spacing, Tubeless Ready |
 BOTTOM BRACKETN/A N/A |
 FRONT TYREVee Tire Co. Attack HPL 29" x 2.5", TOP40 Compound, Enduro Core |
 FRONT DERAILLEURN/A N/A |
REAR TYREVee Tire Co. Attack HPL 27.5" x 2.5", E-Ctrl Compound, Override Core |
 REAR DERAILLEURSRAM GX Eagle 12 Speed |
 Post Mount, Four Piston Caliper |
 12 Speed, Trigger Shifter |
200mm Front & Rear, 6 Bolt Hub Fitment |
 CASSETTESRAM PG-1230 Eagle 12 Speed, 11-50T Range |
 6061 Alloy, 9° Back Sweep, 31.8mm Clamp Diameter, S & M: 760mm Wide, 12mm Rise, L & XL: 780mm Wide, 25mm Rise |
 12 Speed, 118 Links |
 6061 Alloy, 45mm Reach, 0° Rise, 31.8mm Handlebar Clamp Diameter |
 630Wh, Downtube Integrated |
 ZS44/28.6 upper & ZS56/40 lower to suit 1-1/8" upper tapered to 1.5" lower headtube |
 Colour LCD Screen, 5 Modes |
 N/A |
 Mounted on left |
 Black, Steel Rails |
|
Max Power Output 250W, Max Torque 95Nm |
 Remote lever, 31.6mm Diameter, S: 125mm drop, M: 150mm drop, L & XL: 170mm drop |
|
29", 32H, Presta Valve, Tubeless Ready Rim Tape Installed |
 34.9mm Diameter |
-
New Bafang M510 Motor
Bafang’s M510 motor is impressively powerful with a maximum torque of 95Nm powered by a 630Wh integrated battery to give plenty of range. We developed a close partnership with Bafang and tuned the system to perform exactly to our needs. With five custom tuned power modes for adjusting range and on-trail performance and a competitive system weight the M510 is the perfect drive unit to power the E-Mythique LT.
-
Five Custom Tuned Power Modes
• Eco: Lowest level of assistance, great for preserving range on gradual climbs and riding with friends who aren’t on e-bikes.
• Eco+: Moderate assistance with low battery consumption, great on basic trails and fire roads.
• Trail: A versatile mode that’ll cover all your needs for most scenarios. A progressive power curve means assistance increases as you increase your effort.
• Boost: Maximum assistance with full power and torque for effective control on steep and technical climbs.
• Race: Maximum assistance with quicker application of power and torque at lower pedalling force, great for steep technical climbs with lots of obstacles.
-
Suspension Kinematics
The E-Mythique features a progressive leverage ratio that results in a supportive ride feel in mid to deep travel events and means that the E-Mythique LT also works well with coil shocks. Balancing the anti-squat and anti-rise characteristics allows the bike to pedal well in climbing gears while keeping an active feel, helping to keep grip high in descending gears.
Geometry & Sizing
| Frame Size | S | M | L | XL |
| Rec Rider Height (Imperial) | 5' 2" - 5' 6" | 5' 6" - 5' 10" | 5' 10" - 6' 2" | 6' 2" - 6' 7" |
| Rec Rider Height (Metric) | 160 - 170cm | 170 - 178cm | 178 - 190cm | 190 - 201cm |
| Rec Inside Leg (Imperial) | 27" - 30" | 30" - 32" | 32" - 34" | 34" - 37" |
| Rec Inside Leg (Metric) | 71cm - 76cm | 76cm - 81cm | 81cm - 86cm | 86 - 94cm |
| (A)Seattube Length | 380mm | 410mm | 440mm | 480mm |
| (B) Effective Top Tube Length | 573mm | 591mm | 619mm | 649mm |
| (C) Reach* | S: 438mm | L: 434mm | S: 456mm | L: 450mm | S: 483mm | L: 476mm | S: 510mm | L: 504mm |
| (D) Stack* | S: 625mm | L: 630mm | S: 635mm | L: 638mm | S: 643mm | L: 648mm | S: 652mm | L: 657mm |
| (E) Chainstay Length | 445mm | 445mm | 445mm | 445mm |
| (F) Headtube Length | 100mm | 110mm | 120mm | 130mm |
| (G) Headtube Angle* | S: 64° | L: 63.5° | S: 64° | L: 63.5° | S: 64° | L: 63.5° | S: 64° | L: 63.5° |
| (H) Effective Seat Tube Angle* | S: 78° | L: 77.5° | S: 78° | L: 77.5° | S: 78° | L: 77.5° | S: 78° | L: 77.5° |
| (I) Actual Seat Tube Angle* | S: 73.5° | L: 73° | S: 73.5° | L: 73° | S: 73.5° | L: 73° | S: 73.5° | L: 73° |
| Bottom Bracket Drop* | S: 30mm | L: 26mm | S: 30mm | L: 26mm | S: 30mm | L: 26mm | S: 30mm | L: 26mm |
| Wheelbase | 1224mm | 1244mm | 1275mm | 1307mm |
| Max. Seatpost Insert | 177mm | 215mm | 242mm | 270mm |
| * Alternative Geometries - "S" = Shorter 160mm fork travel model (VR); "L" = Longer 170mm fork travel models (VRS/VRX) | ||||
